SPL Phonitor Xe - pojačalo za slušalice
Garantiramo najnižu cijenu na tržištu!
U slučaju da pronađete isti proizvod po povoljnijoj cijeni,
molimo Vas da nas kontaktirate na:
info@player.hr
Our nonplusultra headphone amplifier.
The Phonitor xe is the nonplusultra standalone headphone amplifier without any compromises. Phonitor Matrix, remote volume control, retro-look VU meter, the optional premium DA converter and the all-superior VOLTAiR technology make the Phonitor xe one of the best headphone amplifiers of our time.
Specifications
Analog inputs: XLR (balanced) and RCA
Input gain (max): 32.5 dBu
Input impedance (RCA): 20 kΩ
Input impedance (XLR): 20 kΩ
Common mode rejection ratio (XLR): 82 dB
Digital Inputs: DAC768 (optional)
AES/EBU (XLR), PCM sample rates: 44.1/48/88.2/96/176.4/192 kHz
Coaxial SPDIF (RCA), PCM sample rates: 44.1/48/88.2/96/176.4/192 kHz
Optical SPDIF (Toslink F06), PCM sample rates: 44.1/48/88.2/96/with Glass fibre <1m: 176.4/192 kHz
USB (B), PCM sample rates: 44.1/48/88.2/96/176.4/192/352.8/384/705.6/768 kHz
USB (B), DSD over PCM (DoP), sample rates: 2.8 (DSD64), 5.6 (DSD128), 11.2 (DSD256) MHz
0 dBFS calibrated to: 15 dBu
Balanced Headphones Output: 4-pol XLR (balanced)
Pin wiring: 1 = L (+), 2 = L (-), 3 = R (+), 4 = R (-)
Source impedance: 0.36 Ω
Damping factor (40 Ω): 180
Frequency range (0 dBu): 10 Hz – 100 kHz
Crosstalk (1 kHz, 0 dBu): -90 dBu
THD + N (1 kHz, 0 dBu): 0.00082 %
Noise (A-weighted): -98 dBu
Output power (1 kHz @ 1 % THD, 250 Ω): 2 x 3.5 W
Output power (1 kHz @ 1 % THD, 32 Ω): 2 x 0.7 W
Dynamic range: 130.5 dB
Standard Headphones Output: 6.35 mm (1/4") TRS Jack
Pin wiring: Tip = Left, Ring = Right, Sleeve = GND
Source impedance: 0.18 Ω
Damping factor (40 Ω): 180
Frequency range (0 dBu): 10 Hz – 100 kHz
Crosstalk (1 kHz, 0 dBu): -90 dB
THD + N (1 kHz, 0 dBu): 0.00082 %
Noise (A-weighted): -103 dBu
Output power (1 kHz @ 1 % THD, 250 Ω): 2 x 5 W
Output power (1 kHz @ 1 % THD, 32 Ω): 2 x 2.7 W
Dynamic range: 135.5 dB
Internal Linear Power Supply with Shielded Toroidal Transformer
Operating voltage for analog audio: +/- 60 V
Operating voltage for relays and LEDs: + 12 V
Mains Power Supply
Mains voltage (selectable, see fuse chamber): 230 V AC / 50; 115 V AC / 60 Hz
Fuse for 230 V: T 0.5 A
Fuse for 115 V: T 1 A
Power consumption: max. 40 VA
Stand-by power consumption: < 0.3 W
Dimensions & Weight
W x H x D (width x height incl. feet x depth): 278 x 100 x 300 mm (11 x 4 x 11.81 inch)
Unit weight: 4.9 kg (10.8 lbs)
Shipping weight (incl. packaging): 5.6 kg (12.35 lbs)
