SPL Marc One - Monitor kontroler
Garantiramo najnižu cijenu na tržištu!
U slučaju da pronađete isti proizvod po povoljnijoj cijeni,
molimo Vas da nas kontaktirate na:
info@player.hr
The Monitor And Recording Controller with innovative features and a 32-bit AD/DA converter. A monitor controller with which you can also record. And both in impressive sound quality.
Monitoring and recording in highest sound quality with up to 32 bit and 768 kHz.
Create perfect mixes on speakers and also on headphones – thanks to the Phonitor Matrix.
For us the sound is always in the foreground. When it sounds good, we like to listen. To get such a sound, you need experience and technical finesse. We have incorporated both into the Series One.
Specifications
Analog inputs & outputs; 6.35 mm (1/4") TRS Jacks
Input gain (max): +22.5 dBu
Line Input 1 (balanced): Input impedance: 20 kΩ
Line Input 1: Common mode rejection: < 60 dB
Line Input 2 (unbalanced): Input impedance: 10 kΩ
Output gain (max.): Speaker Outputs (600 Ω): +22 dBu
Line Output (unbalanced): Output impedance: 75 Ω
Speaker Output 1 (balanced): Output impedance: 150 Ω
Sub Output Low Filter: none (full range)
Sub Output (balanced): Output impedance: 150 Ω
Speaker Output 2 (unbalanced): Output impedance: 75 Ω
Frequency range (-3dB): 10 Hz - 200 kHz
Dynamic range: 121.5 dB
Noise (A-weighted, 600 Ω load): -99 dBu
Total harmonic distortion (0 dBu, 1 kHz): 0.002 %
Crosstalk (1 kHz): < 75 dB
Fade-out attenuation: -93 dB
USB, 32-Bit AD/DA
USB (B), PCM sample rates: 44.1/48/88.2/96/176.4/192/352.8/384/705.6/768 kHz
USB (B), DSD over PCM (DoP), sample rates: 2.8 (DSD64), 5.6 (DSD128), 11.2 (DSD256) MHz
0 dBFS calibrated to: 15 dBu
Noise (A-weighted, 44.1/48 kHz sample rate): -113 dBFS
Dynamic range (44,1/48 kHz sample rate): 113 dB
THD + N (-1 dBFS, 10 Hz – 22 kHz): 0.0012 %
Headphones Output; 6.35 mm (1/4") TRS Jack
Wiring: Tip = Left, Ring = Right, Sleeve = GND
Source impedance: 20 Ω
Frequenzgang (- 3 dB)Frequency range (-3 dB): 10 Hz - 200 kHz
Noise (A-weighted, 600 Ω): -97 dBu
THD + N (0 dBu, 10 Hz – 22 kHz, 600 Ω): 0.002 %
THD + N (0 dBu, 10 Hz – 22 kHz, 32 Ω): 0.013 %
Max output power (1 kHz, 600 Ω): 2 x 190 mW
Max output power (1 kHz, 250 Ω): 2 x 330 mW
Max output power (1 kHz, 47 Ω): 2 x 400 mW
Fade-out attenuation (600 Ω): -99 dB
Crosstalk (1 kHz, 600 Ω): -75 dB
Dynamic range: 117
Internal Power Supply
Operating voltage for analog audio: +/- 17 V
Operating voltage for headphone amplifier: +/- 19 V
Operating voltage for relays and LEDs: +12 V
Operating voltage for digital audio: +3.3 V, +5 V
External Power Supply
AC/DC switching adaptor: Mean Well GE18/12-SC
DC plug: (+) pin 2.1mm; (-) outside ring 5.5mm
Input: 100 - 240 V AC; 50 - 60 Hz; 0.7 A
Output: 12 V DC; 1.5 A
Dimensions & Weight
W x H x D (width x height incl. feet x depth): 210 x 49.6 x 220 mm (8.23 x 1.95 x 8.66 inch)
Unit weight: 1.55 kg (3.4 lbs)
Shipping weight (incl. packaging): 2 kg (4.4 lbs)
