Mastering D/A Converter
Mercury is the first mastering DA-converter in 120V technology. It offers seven digital stereo input sources, all of which can be synchronized with each other or with a word clock. The additional variable output qualifies Mercury as a monitor controller.
Analog inputs & output; XLR (balanced)
Maximum input & output gain: 32.5 dBu
Input impedance: 20 kΩ
Output impedance: 75 Ω
Common mode rejection: -82 dBu
Frequency range (-3 dB): 4 Hz – 300 kHz
Crosstalk (1 kHz): -108 dBu
THD (0 dBu, 1 kHz): 0.000992 %
Noise (A-weighted): -102.5 dBu
Dynamic range: 135 dB
Digital Inputs, DAC768
AES/EBU (XLR), PCM sample rates: 44.1/48/88.2/96/176.4/192 kHz
Coaxial SPDIF (Cinch), PCM sample rates: 44.1/48/88.2/96/176.4/192 kHz
Optisch SPDIF (Toslink F06), PCM sample rates: 44.1/48/88.2/96/with Glass fibre <1 m: 176.4/192 kHz
USB (B), PCM sample rates: 44.1/48/88.2/96/176.4/192/352.8/384/705.6/768 kHz
USB (B), DSD over PCM (DoP), sample rates: 2.8 (DSD64), 5.6 (DSD128), 11.2 (DSD256) MHz
0 dBfs calibrated to: 15 dBu
Internal Linear Power Supply with Shielded Toroidal Transformer
Operating voltage for analog audio: +/- 60 V
Operating voltage for relays and LEDs: + 12 V
Mains Power Supply
Mains voltage (selectable, see fuse chamber): 230 V AC / 50; 115 V AC / 60 Hz
Fuse for 230 V: T 500 mA
Fuse for 115 V: T 1 A
Power consumption: max. 40 VA
Stand-by power consumption: < 0,3 W
Dimensions & Weight
W x H x D (width x height x depth): 482 x 44 x 300 mm
Unit weight: 4.55 kg
Shipping weight (incl. packaging): 6.7 kg
