Stereo Power Amplifier
This small completely analog stereo power amplifier shows everyone that size does not necessarily have anything to do with greatness.
With a power amplification of 2 x 285 W (4 Ω) [2 x 185 W (8 Ω)] or 1 x 450 W (8 Ω, Bridge Mode), this amplifier easily controls any loudspeaker. Thanks to VOLTAiR technology, it is fast, precise and highly efficient with outstanding sound.
Specifications
Analog Input & Thru: XLR (balanced)
Input impedance (THRU not connected): 20 kΩ
Common mode rejection (THRU not connected): -82 dB
Input sensitivity: 6 dBu
Loudspeaker Outputs: Binding posts with ø4mm cable hole (screwable) and banana plug
Output power (RMS, 4 Ω): 2 x 285 W
Output power (RMS, 8 Ω): 2 x 185 W
Harmonic distortion (1 kHz, 8 Ω): < 0.03 %
Output power (RMS, 8 Ω, Bridge Mode): 450 W
Harmonic distortion (1 kHz, 8 Ω, Bridge Mode): < 0.011 %
Output voltage (peak to peak): 74 V
Output voltage (peak to peak, Bridge Mode): 180 V
Output voltage (RMS): 35 V
Output voltage (RMS, Bridge Mode): 86 V
Output impedance (20 Hz – 20 kHz): < 0.031 Ω
Output impedance (20 Hz – 20 kHz, Bridge Mode): < 0.043 Ω
Amplification gain: 26 dB
Amplification gain (Bridge Mode): 32 dB
Damping factor (1 kHz, 8 Ohm): > 300
Damping factor (1 kHz, 8 Ohm, Bridge Mode): > 190
Frequency range (-3dB): 10 Hz – 80 kHz
Noise (A-weighted): -123 dBu
Internal Linear Power Supply with Shielded Toroidal Transformer
Toroidal transformer: 875 VA
Operating voltage (Input stage): +/- 60 V
Operating voltage (power stage): +/- 60 V
Operating voltage for relays, LEDs, AMP CTL: + 12 V
Mains Power Supply
Mains voltage (selectable, see fuse chamber): 230 V AC / 50; 115 V AC / 60 Hz
Fuse 230 V: T 4 A
Fuse 115 V: T 8 A
Power consumption: max. 875 VA
Idle power consumption: 40 W
Stand-by power consumption: < 0.3 W
Dimensions & Weight
W x H x D (width x height incl. feet x depth): 278 x 100 x 342 mm (11 x 4 x 13.5 inch)
Unit weight: 12.8 kg (28.2 lbs)
Shipping weight: 14 kg (30.9 lbs)
